Jamstvo : 36 mjeseci , – AC1200 Dual-Band Wi-Fi – 867 Mbps at 5 GHz and 300 Mbps at 2.4 GHz band
– Flexible Deployment – Supports Passive PoE to carry electrical power and data simultaneously
– Multiple Modes – Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs
– MU-MIMO Technology – Simultaneously transfers data to multiple devices for 2× faster performance
– Boosted Coverage – Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals
– Captive Portal – Offers a designed portal page for heightened security and marketing
Specifications
HARDWARE FEATURES
– Interface: 1× 10/100/1000 Mbps Ethernet Port (Supports Passive PoE)
– Button: Power On/Off Button, WPS Button, Reset Button
– External Power Supply: 12V/1.5A
– Wireless Standards: IEEE802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz
– Dimensions (W×D×H): 225×145.5×37 mm
– Antenna Type: 4 Fixed High Performance Antennas
WIRELESS FEATURES
– Frequency: 2.4 GHz and 5 GHz
– Signal Rate: 867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz
– Reception Sensitivity:
* 5 GHz:
11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm
11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm
11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm
11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm
* 2.4 GHz:
11g 54Mbps: -78 dBm
11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm
11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm
– Transmit Power:
* CE: <20dBm (2.4GHz), <23dBm (5.15GHz~5.25GHz)
* FCC: <30dBm (2.4GHz&5GHz)
- Wireless Modes: Access Point, Range Extender, Client, Multi-SSID
- Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Wireless Multicast Forwarding, DHCP Server, Access Control
- Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions
- DHCP: Server, DHCP Client List
- Quality of Service: WMM
- Advanced Functions: Captive Portal
OTHERS
- Certification: CE, FCC, RoHS
- Package Contents: Wireless Access Point TL-WA1201, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide, PoE Power Injector
- System Requirements:
* Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1,10, MAC OS, NetWare, UNIX or Linux
* Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
* Java-enabled browser
- Environment:
* Operating Temperature: 0°C to 40°C(32°F to 104°F)
* Storage Temperature: -40°C to 70°C (-40°F to 158°F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
- Protocol Support: IPv4, IPv6
